Hitch Weight
2,708 lb.
15,000 lb.
12,400 lb.
2,600 lb.
Exterior Length
42' 6"
Exterior Height
12' 5"
Exterior Width
Fresh Water
48 gal.
Gray Water
85 gal.
Black Water
45 gal.
Awning Size

Specifications Definitions

GVWR (Gross Vehicle Weight Rating) – is the maximum permissible weight of the unit when fully loaded. It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories. For safety and product performance do NOT exceed the GVWR.

GCWR (Gross Combined Weight Rating) – is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle. Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating; see hitch rating label for detail.

GAWR (Gross Axle Weight Rating) – is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by a combination of all axles.

UVW (Unloaded Vehicle Weight)* – is the typical weight of the unit as manufactured at the factory. It includes all weight at the unit’s axle(s) and tongue or pin and LP Gas. The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.

CCC (Cargo Carrying Capacity) ** – is the amount of weight available for fresh potable water, cargo, additional optional equipment and accessories. CCC is equal to GVWR minus UVW. Available CCC should accommodate fresh potable water (8.3 lbs per gallon). Before filling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.

Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.

The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.

Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.

Note: Specifications are subject to change without notice.

  • Phoenix Mid-Profile Fifth Wheels

    • Automotive Painted Front Cap W/ LED Strip Lighting
    • UV-Treated, Weather-Resistant Decals W/ Updated Raised Chrome Logo (3-5 Year Warranty*)
    • Dual-Sided AZDEL® Composite Sidewall Panels (Vacuum Bonded & Aluminum Framed) X2
    • 80% Privacy Tint Safety Glass Windows
    • Extra Thick Slam Latch Pass Through Storage Compartment Doors W/ Magnet Catches (HD Metal Latches)
    • Roof Mounted Solar Panel Prep (Roof Mounted Solar Panel Opt. Avail.)
    • Furrion® Exterior Back-Up & Sideview Camera Prep
    • Marine Grade Exterior Speakers W/LED Lights
    • Electric Awning W/ LED Light Strip & One Hand Pitch Adjustment
    • LED Head Knocker Preventer Lights Under Bed Slide* (Select Models)
    • LED Sewer Hose Hook-Up Lights
    • Solid Step™ Entry (4-Step W/ Extra Large Top Step & LED Entry Step Light)
    • Protective Rear Bumper W/ Accessory Receiver Prep
    • Electric Front Jacks & Electric Rear Stabilizer Jacks (Auto-Level Available)
    • 16" Steel Belted Radial Tires W/ Aluminum Rims (5, 2, 1 Warranty + G-Rated Tires on 7,000 lb. Axle Models)
    • 16" Spare Tire
    • Road Armor® Suspension By Trail Air® W/ Heavy Duty Shackles & Wet Bolts
    • Modern Entertainment Center Prepped for 50" - 55" TV (Articulating TV Swing Arm Bracket W/ TV Opt.)
    • Residential Beauflor Vinyl Flooring in Main Slides & All Living Areas
    • Secret Hidden Hinge Storage (Select Models)*
    • Brazilian Walnut Finished Cabinet Doors W/LED Accent Lighting*
    • Free Standing Table & Four Chairs (Hidden Storage in Chairs)
    • Thomas Payne® Theatre Seating W/ Heat, Massage, LED Lights, & Cup Holders*
    • Thomas Payne®* Memory Foam Tri-Fold HAB Sofa*
    • Dual USB Charging Ports*
    • Ceiling Fan In Living Room (N/A 373MBRB & 367BH)
    • LED Interior Lighting Used Throughout W/ Motion Sensor Lites (Key Areas)*
    • AM/FM Stereo W/ Bluetooth, USB, & Modern Sound Bar
    • Roller Night Shades
    • High BTU Output, Modern Electric Fireplace
    • Large Transom Window At Cooktop Backsplash Location
    • Solid Hardwood Drawer & Cabinet Faces (Pre-Drilled & Screwed Solid Lumber Core Cabinet Stiles)
    • Modern High Rise Kitchen Faucet
    • Full-Extend Ball Bearing Drawer Guides (75 lb. & 100 lb. Guide Capacities)*
    • 8 Cubic Foot Refrigerator (XL Residential & Gas/Electric Options Available)*
    • 30" Residential Microwave
    • 21" Oven W/ Residential Cooktop, Glass Cover, & Piezo Ignition
    • Extra Deep Single Basin Sink (Stainless Steel)
    • <strong>STAND OUT FEATURES (BATH) MID-PROFILE </strong>
    • Full Size Shower W/ Sliding Glass Doors & Seat
    • Large Privacy Dome Skylight
    • Power Ceiling Vent Fan (12 Volt)
    • Heat Duct & A/C Venting W/ Rotating/Closing Louvers
    • Large Sink(s)* W/ Seamless Thermofoil Lav (No T-Mold)
    • Large Linen Closet*
    • Decorative Wood Plank With Metal Towel Hooks
    • LED Motion Sensor Light
    • Porcelain Toilet W/ Foot Flush
    • Residential 60” x 80” Pillow Top Mattress & Bedspread (King Options Where Applicable)
    • Padded Soft Touch Headboard*
    • Bedside Nightstands*
    • Hidden Hinge Storage Under Dresser Top (N/A 367BH, 373MBRB)
    • Dual USB Charging Ports
    • Dual 110 Volt Outlets At Bed*
    • Ducted A/C Vents W/ Rotator/Closing Louvers
    • Bedroom Heat Registers
    • Roller Night Shades
    • Residential 5" Truss Rafters (16" on Center) W/ Full Walk on 3/8" Roof Decking
    • Tri-Tex Powder Coated Frame Technology (Up To 5X More Weather Resistance!)
    • Dual-Sided AZDEL® Composite Sidewall Panels (Vacuum Bonded & Aluminum Framed) X2
    • Weather Shield+™ 0° Cold Tested & 110° Hot Tested (Extreme Temperature Chamber): Space Age Reflective Technology (Underbelly, Roof, Slides & More!), Unobstructed & Insulated Pass-Thru Storage (W/ Built-In Tool Storage), Ducted Furnace to Enclosed, Insulated, & Heated Underbelly + Gate Valves (Circulating Heat), R15+ Sidewalls, R47+ Floor, R37+ Roof (Equivalency, Based on 80° F W/ Radiant Barrier) (P)
    • USA-Made Dexter® E-Z Lube® Axles W/5-Year Defect and Lifetime Weld Warranty!
    • Roof Mounted Solar Panel Prep (Roof Mounted Solar Panel Opt. Avail.)
    • LP Quick Connect Port
    • 50 AMP Service W/ Detachable Marine Cord W/ LED Indicator
    • 15,000 BTU Ducted Main Air Conditioner + 15,000 BTU Ducted Bedroom Air Conditioner
    • Dual Zone Thermostat/Controller
    • Quick Recovery 10 Gallon Gas/Elec. Hot Water Heater (20 GPH)
    • RV Battery & Battery Box
    • 12 Volt Battery Disconnect Switch
    • Winegard® Air 360+™ HDTV/Radio Dome Antenna
    • Prepped for Available Winegard Gateway Model: GW-1000 (Adds 4G LTE & Wi-Fi Capabilities)
    • Satellite & Cable TV Hook-Up W/ Independent Satellite Feeds
    • Washer/Dryer Prep
    • Outside Convenience Center W/ Black Tank Flush, Hot/Cold Shower, Water Filtration Prep, & WH Bypass
    • <strong>INTERIOR OPTIONS</strong>
    • 50" HD LED TV (334, 336, 360, 367 & 375 Only)
    • Solid Surface Counter Tops
    • King Bed IPO Standard Queen (334, 336 & 375)
    • 10.7 cu. ft. 12V Refrigerator in place of 8 cu. ft. Gas Electric Refrigerator
    • 12 cu. ft. Gas/Electric Refrigerator IPO 8 cu. ft. Gas/Electric Refrigerator (N/A 360)
    • 17 cu. ft. 12V Refrigerator IPO 8 cu. ft. Gas/Electric Refrigerator (N/A 360)
    • Comfort Air Fan in Kitchen
    • <strong>EXTERIOR OPTIONS</strong>
    • 3rd 15,000 BTU A/C (N/A 298, 336)
    • 6-Point Electric Auto-Leveling (334 & Larger)
    • Electronic Heated Holding Tanks
    • 2" Accessory Receiver Hitch (N/A 360)
    • Roof Mounted Solar Panel
